Trimming Table – Rectangular Large Animal with Lift and Tilt – OA200

  • Dimensions: 84″ long x 48″ wide x 42″ elevating height


  • In-floor mounted pit-pit preparation provided by others to Mopec specification
  • .75″ to 1″ tilted top for drainage to pit drain
  • Heavy duty stainless steel top
  • Designed to handle a centralized load up to 2 000 pounds
  • Safety toe guard
  • Drain hole with removable mesh screen
  • Hydraulic lift system with hand held switch
  • Electrical Requirement: 115 V
  • NEMA 4-Internal mounted pump system
  •  Other load capacities are available
Read More
SKU: OA200 Category:


The OA200 Series are large capacity elevating tables capable of supporting heavy loads. Designed for necropsy on large animals. The OA200 Series are designed so that when they initially elevate a tilt will be incurred allowing for the mechanism that holds the animal to be locked securely in place and not roll off the table. The OA200 Series is also provided with a drain hole with removable perforated screen to help collect debris. Has a hydraulic scissor lift and hydraulic pump unit. Designed to fit within a pit of the room in its lowered position the tables will be flush with the finish floor line. Available in a rectangular or kidney shape and with or without casters.

Request Technical Drawing
